Robot Arm Fundamentals: Kinematics & Dynamics for Control

Before a robot arm can perform any task — from simple pick-and-place to precision welding — you need to understand two core pillars: Kinematics (describing geometric motion) and Dynamics (describing forces and torques). This is the first post in the Traditional Manipulation Control series, where we build from mathematical foundations to real-world robot deployment.

Why Kinematics and Dynamics Matter

Imagine you are commanding a 6-DOF robot arm to grasp an object at position [x, y, z] in space. The first question: how much should each joint rotate? That is the Inverse Kinematics (IK) problem. The next question: how much torque is needed at each joint to move? That is Dynamics.

Without mastering these two concepts, you cannot:

• Plan accurate trajectories
• Avoid singularities
• Control contact forces during grasping
• Optimize speed and energy consumption

DH Parameters — The Universal Language for Describing Robots

Denavit-Hartenberg (DH) parameters provide a standardized way to describe robot arm geometry. Each joint is characterized by 4 parameters:

The transformation matrix from frame $i-1$ to frame $i$:

T_i = Rot_z(θ_i) × Trans_z(d_i) × Trans_x(a_i) × Rot_x(α_i)

Comparing DH Parameters: UR5e vs Panda

The UR5e is a 6-DOF robot (spherical wrist — 3 axes intersecting at one point), while the Panda is 7-DOF (redundant — one extra degree of freedom, more flexible but IK is more complex).

Forward Kinematics (FK) — From Joints to Position

Forward Kinematics answers: "Given all joint angles, where is the end-effector?"

The formula is straightforward — chain-multiply transformation matrices:

T_0^n = T_1 × T_2 × ... × T_n

The matrix $T_0^n$ (4×4) contains:

• Rotation matrix (3×3): end-effector orientation
• Translation vector (3×1): position [x, y, z]

Code: Forward Kinematics with roboticstoolbox-python

import roboticstoolbox as rtb
import numpy as np

# Create UR5e robot from library
ur5e = rtb.models.UR5()

# Set joint angles (radians)
q = np.array([0, -np.pi/4, np.pi/4, -np.pi/2, np.pi/2, 0])

# Forward Kinematics — compute end-effector pose
T = ur5e.fkine(q)
print("End-effector pose:")
print(T)
print(f"\nPosition: x={T.t[0]:.4f}, y={T.t[1]:.4f}, z={T.t[2]:.4f}")

# Visualize robot
ur5e.plot(q, block=True)

FK always has exactly one solution — this is a key difference from IK.

Inverse Kinematics (IK) — From Position to Joints

Inverse Kinematics is the reverse problem: "Given a desired end-effector pose, find the joint angles."

This problem is much harder because:

1. Multiple solutions: A 6-DOF robot can have up to 16 IK solutions
2. No solution: Position is outside the workspace
3. Infinite solutions: 7-DOF (redundant) robots

Two Approaches to IK

Analytical IK for Spherical Wrist Robots

The UR5e has a spherical wrist (last 3 axes intersect), allowing problem decomposition:

1. Position IK: Find $\theta_1, \theta_2, \theta_3$ from wrist center position
2. Orientation IK: Find $\theta_4, \theta_5, \theta_6$ from end-effector orientation

The IKFast algorithm (from OpenRAVE) can automatically generate analytical IK code for any robot with a suitable structure.

Numerical IK

import roboticstoolbox as rtb
import numpy as np
from spatialmath import SE3

ur5e = rtb.models.UR5()

# Desired pose: [x=0.5, y=0.2, z=0.3], pointing straight down
T_desired = SE3(0.5, 0.2, 0.3) * SE3.Rx(np.pi)

# Levenberg-Marquardt method (numerical)
sol = ur5e.ikine_LM(T_desired)
print(f"IK solution found: {sol.success}")
print(f"Joint angles (deg): {np.degrees(sol.q)}")

# Verify: run FK to check
T_actual = ur5e.fkine(sol.q)
pos_error = np.linalg.norm(T_desired.t - T_actual.t)
print(f"Position error: {pos_error*1000:.2f} mm")

Jacobian Matrix — Bridging Joint and End-Effector Velocities

The Jacobian ($J$) is a 6×n matrix relating joint velocities ($\dot{q}$) to end-effector velocity ($v$):

v = J(q) × q̇

Where $v = [v_x, v_y, v_z, \omega_x, \omega_y, \omega_z]^T$ (linear + angular velocity).

What is the Jacobian Used For?

1. Cartesian velocity control: $\dot{q} = J^{-1} v$
2. Singularity detection: When $\det(J) \approx 0$, the robot loses degrees of freedom
3. End-effector force computation: $F = J^T \tau$ (mapping joint torques to Cartesian forces)
4. Resolved-rate control: Controlling the robot along Cartesian trajectories

Singularity — The Robot's "Dead Points"

Singularity occurs when the Jacobian becomes rank-deficient. At singularity:

• The robot loses the ability to move in one or more directions
• Joint velocities blow up ($J^{-1}$ does not exist)

Three common singularity types for 6-DOF robots:

1. Shoulder singularity: Wrist center lies on joint 1 axis
2. Elbow singularity: Arm is fully extended
3. Wrist singularity: Two wrist axes align ($\theta_5 = 0$)

# Compute Jacobian and check singularity
J = ur5e.jacob0(q)
manipulability = np.sqrt(np.linalg.det(J @ J.T))
print(f"Manipulability index: {manipulability:.4f}")

if manipulability < 0.01:
    print("WARNING: Near singularity!")

Dynamics — Force and Torque Modeling

While kinematics only considers the geometry of motion, dynamics considers the forces that cause motion. The general dynamics equation:

τ = M(q)q̈ + C(q, q̇)q̇ + g(q) + J^T F_ext

Two Methods for Computing Dynamics

Lagrangian (Energy-based):

• Compute kinetic energy ($T$) and potential energy ($V$): $L = T - V$
• Apply Euler-Lagrange equations
• Advantage: Yields symbolic expressions
• Disadvantage: Computationally expensive for many DOFs

Newton-Euler (Force-based):

• Forward pass: Compute velocities, accelerations from base to end-effector
• Backward pass: Compute forces, torques from end-effector to base
• Advantage: Computationally efficient $O(n)$, suitable for real-time
• Disadvantage: Harder to obtain symbolic expressions

import roboticstoolbox as rtb
import numpy as np

ur5e = rtb.models.UR5()
q = np.array([0, -np.pi/4, np.pi/4, -np.pi/2, np.pi/2, 0])
qd = np.zeros(6)  # Zero joint velocities

# Gravity torque — torque needed to hold the robot stationary
tau_g = ur5e.gravload(q)
print(f"Gravity torques (Nm): {np.round(tau_g, 2)}")

# Inertia matrix
M = ur5e.inertia(q)
print(f"\nInertia matrix shape: {M.shape}")
print(f"Condition number: {np.linalg.cond(M):.1f}")

# Inverse dynamics — compute torques for desired trajectory
qdd = np.array([0.1, 0.2, -0.1, 0.05, -0.05, 0.1])  # Desired acceleration
tau = ur5e.rne(q, qd, qdd)
print(f"\nRequired torques (Nm): {np.round(tau, 2)}")

Workspace Analysis — How Far Can the Robot Reach?

The workspace is the set of all positions the end-effector can reach. We distinguish:

• Reachable workspace: Positions reachable with at least one orientation
• Dexterous workspace: Positions reachable with any orientation

import roboticstoolbox as rtb
import numpy as np
import matplotlib.pyplot as plt

ur5e = rtb.models.UR5()

# Monte Carlo workspace sampling
n_samples = 10000
positions = []

for _ in range(n_samples):
    q_random = ur5e.random_q()
    T = ur5e.fkine(q_random)
    positions.append(T.t)

positions = np.array(positions)

# Visualize workspace
fig, axes = plt.subplots(1, 2, figsize=(14, 6))

axes[0].scatter(positions[:, 0], positions[:, 1], s=1, alpha=0.3, c='blue')
axes[0].set_xlabel('X (m)')
axes[0].set_ylabel('Y (m)')
axes[0].set_title('Workspace — Top View (XY)')
axes[0].set_aspect('equal')
axes[0].grid(True)

axes[1].scatter(positions[:, 0], positions[:, 2], s=1, alpha=0.3, c='red')
axes[1].set_xlabel('X (m)')
axes[1].set_ylabel('Z (m)')
axes[1].set_title('Workspace — Side View (XZ)')
axes[1].set_aspect('equal')
axes[1].grid(True)

plt.tight_layout()
plt.savefig('ur5e_workspace.png', dpi=150)
plt.show()

Practical Application: FK/IK in Pick-and-Place

A basic pick-and-place workflow using FK and IK:

1. Camera detects object -> Cartesian coordinates [x, y, z]
2. IK -> Compute joint angles to position gripper at grasp pose
3. FK verification -> Verify actual position after movement
4. Jacobian -> Control slow approach (resolved-rate)

# Simple pick-and-place workflow
import roboticstoolbox as rtb
import numpy as np
from spatialmath import SE3

ur5e = rtb.models.UR5()

# Pick position (from camera)
pick_pos = SE3(0.4, 0.3, 0.1) * SE3.Rx(np.pi)

# Approach position (10cm above)
approach_pos = SE3(0.4, 0.3, 0.2) * SE3.Rx(np.pi)

# Place position
place_pos = SE3(-0.3, 0.4, 0.15) * SE3.Rx(np.pi)

# Solve IK for each position
q_approach = ur5e.ikine_LM(approach_pos).q
q_pick = ur5e.ikine_LM(pick_pos).q
q_place = ur5e.ikine_LM(place_pos).q

# Check manipulability at each point
for name, q in [("Approach", q_approach), ("Pick", q_pick), ("Place", q_place)]:
    J = ur5e.jacob0(q)
    m = np.sqrt(np.linalg.det(J @ J.T))
    print(f"{name}: manipulability = {m:.4f}")

References

• Craig, J.J. Introduction to Robotics: Mechanics and Control (4th ed.). Pearson, 2017. DOI: 10.1109/MRA.2005.1577021
• Siciliano, B., Sciavicco, L., Villani, L., Oriolo, G. Robotics: Modelling, Planning and Control. Springer, 2009. DOI: 10.1007/978-1-84628-642-1
• Diankov, R. Automated Construction of Robotic Manipulation Programs (IKFast). PhD Thesis, CMU, 2010. Link
• Corke, P. Robotics, Vision and Control (3rd ed.). Springer, 2023. DOI: 10.1007/978-3-031-07262-8

Conclusion

Kinematics and dynamics are the indispensable foundation for working with robot arms. In this post, we covered:

• DH parameters — standardized geometric description
• FK and IK — converting between joint space and Cartesian space
• Jacobian — velocity mapping and singularity detection
• Dynamics — force modeling with Lagrangian and Newton-Euler methods

In the next post, we will use this knowledge to build trajectory planning — planning paths in Joint Space and Cartesian Space.
