Reward Engineering for Bipedal Walking: The Art of Reward Design

If the observation space is the robot's "eyes," then the reward function is its "soul" — it shapes every behavior the policy learns. Designing rewards for bipedal walking is more art than science: too few reward terms and the robot learns bizarre gaits, too many and training won't converge.

In the previous post — Fundamentals & Environment Setup — we set up the environment. Now, let's dive into the hardest part: designing the reward function.

Overview of Reward Engineering

Why Is Reward Design Hard?

Bipedal walking has many simultaneous objectives:

• Walk at the desired velocity
• Keep the torso upright
• Lift feet high enough (foot clearance)
• Conserve energy
• Move smoothly (no jerkiness)
• Coordinate legs in alternating rhythm

Each objective requires its own reward term, and the weights between terms determine the final behavior.

Reward Hacking — Enemy Number One

Reward hacking occurs when the policy finds a way to maximize reward without actually doing what you want. Classic examples:

12+ Reward Terms for Bipedal Walking

Below is a complete reward function with detailed explanations for each term:

import torch
import numpy as np

class BipedalRewardFunction:
    """
    Complete reward function for humanoid bipedal walking.
    Synthesized from Humanoid-Gym, Walk These Ways, and practical experience.
    """

    def __init__(self, cfg):
        # Reward weights — THIS IS WHERE THE MAGIC HAPPENS
        self.weights = {
            # === Tracking rewards (primary objectives) ===
            "linear_vel_tracking": 1.5,    # Track desired velocity
            "angular_vel_tracking": 0.8,   # Track desired yaw rate

            # === Posture rewards (balance) ===
            "upright": 0.5,                # Keep torso upright
            "base_height": 0.3,            # Maintain stable height

            # === Gait quality rewards ===
            "foot_clearance": 0.3,         # Lift feet high enough
            "contact_pattern": 0.4,        # Alternate feet properly
            "foot_slip": -0.1,             # Penalize foot slipping

            # === Smoothness rewards ===
            "action_rate": -0.01,          # Penalize sudden action changes
            "torque": -0.00005,            # Penalize large torques
            "joint_acceleration": -0.0001, # Penalize joint acceleration

            # === Safety rewards ===
            "termination": -200.0,         # Heavy penalty for falling
            "joint_limit": -1.0,           # Penalize hitting joint limits

            # === Style rewards (optional) ===
            "feet_air_time": 0.2,          # Reward natural swing time
        }

    def compute_reward(self, state, action, prev_action, command):
        """Compute total reward from all terms."""
        rewards = {}

        # 1. Linear velocity tracking
        # Most important — robot must walk at requested speed
        vel_error = torch.sum(
            torch.square(command[:, :2] - state["base_lin_vel"][:, :2]),
            dim=1
        )
        rewards["linear_vel_tracking"] = torch.exp(-vel_error / 0.25)

        # 2. Angular velocity tracking (yaw rate)
        yaw_error = torch.square(
            command[:, 2] - state["base_ang_vel"][:, 2]
        )
        rewards["angular_vel_tracking"] = torch.exp(-yaw_error / 0.25)

        # 3. Upright posture
        # projected_gravity[2] = -1 when perfectly upright
        rewards["upright"] = torch.square(state["projected_gravity"][:, 2] + 1.0)

        # 4. Base height
        # Keep height near target (0.72m for G1)
        target_height = 0.72
        height_error = torch.square(state["base_height"] - target_height)
        rewards["base_height"] = torch.exp(-height_error / 0.05)

        # 5. Foot clearance
        # Reward when swing foot lifts above 0.06m
        swing_mask = state["foot_contact"] < 0.5
        foot_height = state["foot_height"]
        clearance_reward = torch.where(
            swing_mask,
            torch.clamp(foot_height - 0.06, min=0.0),
            torch.zeros_like(foot_height)
        )
        rewards["foot_clearance"] = torch.sum(clearance_reward, dim=1)

        # 6. Contact pattern — feet must alternate
        left_contact = state["foot_contact"][:, 0]
        right_contact = state["foot_contact"][:, 1]
        both_air = (1 - left_contact) * (1 - right_contact)
        rewards["contact_pattern"] = -both_air

        # 7. Foot slip penalty
        contact_mask = state["foot_contact"] > 0.5
        foot_vel = torch.norm(state["foot_velocity"][:, :, :2], dim=2)
        slip = contact_mask * foot_vel
        rewards["foot_slip"] = -torch.sum(slip, dim=1)

        # 8. Action rate penalty
        action_diff = torch.sum(torch.square(action - prev_action), dim=1)
        rewards["action_rate"] = -action_diff

        # 9. Torque penalty
        torques = state["applied_torques"]
        rewards["torque"] = -torch.sum(torch.square(torques), dim=1)

        # 10. Joint acceleration penalty
        joint_acc = state["joint_accelerations"]
        rewards["joint_acceleration"] = -torch.sum(torch.square(joint_acc), dim=1)

        # 11. Termination penalty
        rewards["termination"] = state["is_terminated"].float()

        # 12. Joint limit penalty
        joint_pos = state["joint_positions"]
        lower = state["joint_lower_limits"]
        upper = state["joint_upper_limits"]
        margin = 0.1
        below = torch.clamp(lower + margin - joint_pos, min=0.0)
        above = torch.clamp(joint_pos - upper + margin, min=0.0)
        rewards["joint_limit"] = -torch.sum(below + above, dim=1)

        # 13. Feet air time (style reward)
        target_air_time = 0.3
        air_time_error = torch.abs(
            state["feet_air_time"] - target_air_time
        )
        rewards["feet_air_time"] = torch.sum(
            torch.exp(-air_time_error / 0.1), dim=1
        )

        # Compute weighted total
        total_reward = torch.zeros(state["base_height"].shape[0])
        for name, value in rewards.items():
            total_reward += self.weights[name] * value

        return total_reward, rewards

Reward Weighting Strategies

Method 1: Manual Tuning (Most Common)

Start with default weights, train for ~30 minutes, watch behavior videos, and adjust:

# Iteration 1: Robot dives forward
weights_v1 = {"linear_vel_tracking": 2.0, "upright": 0.1}
# -> Increase upright, decrease velocity

# Iteration 2: Robot stands still, very upright
weights_v2 = {"linear_vel_tracking": 1.0, "upright": 1.0}
# -> Better balanced, but robot doesn't lift feet

# Iteration 3: Add foot clearance + contact pattern
weights_v3 = {
    "linear_vel_tracking": 1.5,
    "upright": 0.5,
    "foot_clearance": 0.3,
    "contact_pattern": 0.4,
}
# -> Robot starts walking!

Method 2: Exponential Reward Scaling

Instead of linear rewards, use exponential to create a sharp peak near the target:

def exponential_tracking_reward(error, sigma=0.25):
    """
    exp(-error^2 / sigma) creates a bell-shaped reward.
    - Small sigma: only rewards when very close to target
    - Large sigma: rewards even when far from target
    """
    return torch.exp(-torch.square(error) / sigma)

# Velocity tracking with sigma=0.25
vel_reward = exponential_tracking_reward(vel_error, sigma=0.25)

# Height tracking with sigma=0.05 (stricter)
height_reward = exponential_tracking_reward(height_error, sigma=0.05)

Method 3: Adaptive Reward Scaling

Automatically adjust weights based on training progress:

class AdaptiveRewardScaler:
    """Auto-scale rewards to maintain equivalent magnitudes."""

    def __init__(self, reward_names, target_magnitude=1.0):
        self.ema = {name: target_magnitude for name in reward_names}
        self.alpha = 0.99

    def scale(self, rewards_dict):
        scaled = {}
        for name, value in rewards_dict.items():
            mag = torch.abs(value).mean().item()
            self.ema[name] = self.alpha * self.ema[name] + (1 - self.alpha) * mag

            if self.ema[name] > 1e-6:
                scaled[name] = value / self.ema[name]
            else:
                scaled[name] = value
        return scaled

Reward Curriculum: From Standing to Walking

Instead of training walking from scratch, curriculum learning helps stabilize training:

Phase 1: Standing (0-500 iterations)

curriculum_phase_1 = {
    "linear_vel_tracking": 0.0,     # Don't need to walk yet
    "upright": 2.0,                  # Priority: stand upright
    "base_height": 1.0,             # Maintain height
    "termination": -200.0,          # Penalize falling
    "torque": -0.0001,              # Energy efficiency
}
# Command velocity = [0, 0, 0]

Phase 2: Weight Shifting (500-1500 iterations)

curriculum_phase_2 = {
    "linear_vel_tracking": 0.3,     # Start tracking small velocity
    "upright": 1.5,
    "base_height": 0.8,
    "contact_pattern": 0.2,         # Start requiring foot alternation
    "foot_clearance": 0.1,
    "termination": -200.0,
    "torque": -0.0001,
}
# Command velocity = [0.2, 0, 0]  # slow

Phase 3: Walking (1500-5000 iterations)

curriculum_phase_3 = {
    "linear_vel_tracking": 1.5,     # Full tracking
    "angular_vel_tracking": 0.8,
    "upright": 0.5,
    "base_height": 0.3,
    "foot_clearance": 0.3,
    "contact_pattern": 0.4,
    "foot_slip": -0.1,
    "action_rate": -0.01,
    "torque": -0.00005,
    "joint_acceleration": -0.0001,
    "termination": -200.0,
    "joint_limit": -1.0,
    "feet_air_time": 0.2,
}
# Command velocity = random[-1.0, 1.0] m/s

class RewardCurriculum:
    """Reward curriculum manager."""

    def __init__(self):
        self.phases = [
            (0, curriculum_phase_1),
            (500, curriculum_phase_2),
            (1500, curriculum_phase_3),
        ]

    def get_weights(self, iteration):
        """Return weights appropriate for current iteration."""
        current_weights = self.phases[0][1]
        for threshold, weights in self.phases:
            if iteration >= threshold:
                current_weights = weights
        return current_weights

    def get_command_range(self, iteration):
        """Gradually increase command velocity range."""
        if iteration < 500:
            return {"vx": [0, 0], "vy": [0, 0], "yaw": [0, 0]}
        elif iteration < 1500:
            return {"vx": [0, 0.3], "vy": [-0.1, 0.1], "yaw": [-0.2, 0.2]}
        else:
            progress = min((iteration - 1500) / 3500, 1.0)
            max_vx = 0.3 + progress * 0.7
            return {
                "vx": [-0.3, max_vx],
                "vy": [-0.3 * progress, 0.3 * progress],
                "yaw": [-0.5 * progress, 0.5 * progress],
            }

Ablation Study: What Does Each Reward Term Contribute?

The table below summarizes results when removing each reward term:

Comparing Reward Formulations from Papers

Pitfalls and Best Practices

Pitfall 1: Reward Magnitude Mismatch

# WRONG: vel_tracking ~1.0 but torque ~10000
rewards = vel_reward + 0.001 * torque_penalty
# Despite small weight, torque penalty still dominates gradient

# RIGHT: Normalize before weighting
rewards = vel_reward + 0.001 * (torque_penalty / torque_scale)

Pitfall 2: Sparse vs Dense Rewards

# WRONG: Only reward reaching the goal (sparse)
reward = 100.0 if reached_goal else 0.0
# Robot has no signal about correct direction until random goal reach

# RIGHT: Reward continuous progress (dense)
reward = -distance_to_goal + velocity_toward_goal

Pitfall 3: Forgetting Termination Penalty

# WRONG: No penalty for falling
# Robot will try risky behaviors since there's no penalty

# RIGHT: Heavy penalty for falling
if is_terminated:
    reward -= 200.0

To learn more about quadruped locomotion (a simpler problem with the same principles), see Quadruped Locomotion with RL.

Summary

Reward engineering for bipedal walking is not "set and forget" — it is an iterative process: design, train, watch videos, adjust. Key takeaways:

1. 12+ reward terms are necessary for natural gaits
2. Exponential tracking is better than linear for velocity/height targets
3. Reward curriculum (standing, walking, running) stabilizes training
4. Ablation study reveals each term's importance
5. Reward hacking is the enemy — always watch behavior videos, not just reward curves

Next post — Unitree G1: Training a Walking Policy from Scratch — applies all this knowledge to real training on the Unitree G1 in Isaac Lab.

References

1. Walk These Ways: Tuning Robot Control for Generalization with Multiplicity of Behavior — Margolis & Agrawal, CoRL 2023
2. Sim-to-Real Learning of All Common Bipedal Gaits via Periodic Reward Composition — Siekmann et al., ICRA 2021
3. Humanoid-Gym: Reinforcement Learning for Humanoid Robot — Gu et al., 2024
4. Learning Humanoid Locomotion with Transformers — Radosavovic et al., 2024
