Sim-to-Real Transfer: Deploy VLA Policy lên Robot thật

Bài cuối cùng: Từ Simulation đến Thế giới thật

Xuyên suốt 9 bài trước, chúng ta đã xây dựng mọi thứ trong simulation: thu thập data bằng teleop, train single-arm, multi-object, dual-arm, mobile manipulation, và humanoid. Nhưng simulation chỉ là bước đệm — mục tiêu cuối cùng luôn là robot thật hoạt động trong thế giới thật.

Sim-to-real transfer là nơi mà rất nhiều project thất bại. Policy đạt 95% success rate trong sim nhưng 0% trên real robot. Bài này sẽ giúp bạn tránh những cạm bẫy đó với pipeline đã được kiểm chứng.

Tại sao Sim-to-Real khó?

Reality Gap

Nghiên cứu từ Tobin et al. (2017) đã chỉ ra rằng domain randomization là chìa khóa để bridge reality gap, nhưng nó chỉ là một phần của puzzle.

Domain Randomization cho Visual Policies

Visual Randomization

VLA policies dựa rất nhiều vào camera input. Visual domain randomization là critical:

# LeRobot visual domain randomization config
visual_randomization = {
    # Camera randomization
    "camera_position_noise": 0.02,       # ±2cm position noise
    "camera_rotation_noise": 3.0,        # ±3 degrees rotation
    "camera_fov_range": [55, 75],        # Field of view range

    # Lighting randomization
    "light_intensity_range": [0.3, 1.5],
    "light_color_range": [0.8, 1.2],     # Per-channel multiplier
    "light_position_noise": 0.5,         # ±50cm
    "num_random_lights": [1, 4],

    # Texture randomization
    "table_texture_randomize": True,
    "object_color_randomize": True,
    "background_randomize": True,

    # Post-processing
    "brightness_range": [0.7, 1.3],
    "contrast_range": [0.8, 1.2],
    "saturation_range": [0.8, 1.2],
    "noise_std_range": [0.0, 0.02],
}

Physics Randomization

# Physics domain randomization
physics_randomization = {
    # Object properties
    "object_mass_range": [0.8, 1.2],      # ±20% mass
    "object_friction_range": [0.3, 1.5],
    "object_size_range": [0.9, 1.1],      # ±10% size

    # Robot properties
    "joint_friction_range": [0.5, 2.0],
    "joint_damping_range": [0.8, 1.2],
    "actuator_strength_range": [0.9, 1.1],

    # Control
    "action_delay_range": [0, 3],         # 0-3 frames delay
    "action_noise_std": 0.01,
    "observation_delay_range": [0, 2],

    # Environment
    "gravity_noise": 0.05,                # ±5% gravity
    "table_height_range": [-0.02, 0.02],  # ±2cm
}

Paper Domain Randomization for Transferring Deep Neural Networks from Simulation to the Real World (Tobin et al., 2017) đã chứng minh rằng chỉ cần randomize đủ rộng, policy sẽ học features invariant giữa sim và real.

Camera Calibration và Real-World Setup

Camera Setup

Camera placement phải match giữa sim và real — đây là lỗi phổ biến nhất:

import numpy as np
import cv2

def calibrate_camera(images_dir, checkerboard_size=(9, 6)):
    """Camera calibration using checkerboard pattern."""
    criteria = (cv2.TERM_CRITERIA_EPS + cv2.TERM_CRITERIA_MAX_ITER, 30, 0.001)

    objp = np.zeros((checkerboard_size[0] * checkerboard_size[1], 3), np.float32)
    objp[:, :2] = np.mgrid[0:checkerboard_size[0],
                           0:checkerboard_size[1]].T.reshape(-1, 2)

    objpoints, imgpoints = [], []

    import glob
    images = glob.glob(f"{images_dir}/*.png")

    for fname in images:
        img = cv2.imread(fname)
        gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
        ret, corners = cv2.findChessboardCorners(gray, checkerboard_size, None)

        if ret:
            objpoints.append(objp)
            corners2 = cv2.cornerSubPix(gray, corners, (11, 11), (-1, -1), criteria)
            imgpoints.append(corners2)

    ret, mtx, dist, rvecs, tvecs = cv2.calibrateCamera(
        objpoints, imgpoints, gray.shape[::-1], None, None
    )

    print(f"Reprojection error: {ret:.4f}")
    print(f"Camera matrix:\n{mtx}")
    print(f"Distortion coefficients: {dist}")

    return mtx, dist

# Calibrate
mtx, dist = calibrate_camera("calibration_images/")

Extrinsic Calibration (Camera-to-Robot)

def hand_eye_calibration(robot_poses, camera_poses):
    """
    AX = XB hand-eye calibration.
    robot_poses: list of 4x4 homogeneous transforms (base to end-effector)
    camera_poses: list of 4x4 transforms (camera to calibration target)
    """
    R_gripper2base = [pose[:3, :3] for pose in robot_poses]
    t_gripper2base = [pose[:3, 3] for pose in robot_poses]
    R_target2cam = [pose[:3, :3] for pose in camera_poses]
    t_target2cam = [pose[:3, 3] for pose in camera_poses]

    R_cam2gripper, t_cam2gripper = cv2.calibrateHandEye(
        R_gripper2base, t_gripper2base,
        R_target2cam, t_target2cam,
        method=cv2.CALIB_HAND_EYE_TSAI
    )

    T_cam2gripper = np.eye(4)
    T_cam2gripper[:3, :3] = R_cam2gripper
    T_cam2gripper[:3, 3] = t_cam2gripper.flatten()

    return T_cam2gripper

Inference Optimization

Quantization cho Real-Time Inference

VLA models (7B+ params) cần optimization để chạy real-time:

from transformers import AutoModelForVision2Seq, BitsAndBytesConfig
import torch

# 8-bit quantization
quantization_config = BitsAndBytesConfig(
    load_in_8bit=True,
    llm_int8_threshold=6.0,
)

model = AutoModelForVision2Seq.from_pretrained(
    "openvla/openvla-7b-finetuned",
    quantization_config=quantization_config,
    device_map="auto",
    torch_dtype=torch.float16,
)

# Benchmark inference speed
import time

# Warm up
for _ in range(5):
    with torch.no_grad():
        _ = model.predict_action(dummy_obs)

# Measure
times = []
for _ in range(100):
    start = time.perf_counter()
    with torch.no_grad():
        action = model.predict_action(obs)
    times.append(time.perf_counter() - start)

print(f"Inference: {np.mean(times)*1000:.1f}ms ± {np.std(times)*1000:.1f}ms")
print(f"Control frequency: {1/np.mean(times):.1f} Hz")

Performance Comparison

Với robot arm thông thường, control frequency 5-10 Hz là đủ, nên INT8 (~95ms) hoạt động tốt. Nếu cần nhanh hơn, TensorRT là lựa chọn tốt nhất nhưng yêu cầu conversion phức tạp hơn.

ROS 2 Deployment Node

Complete ROS 2 Policy Server

#!/usr/bin/env python3
"""ROS 2 node for VLA policy deployment."""

import rclpy
from rclpy.node import Node
from sensor_msgs.msg import Image, JointState
from trajectory_msgs.msg import JointTrajectoryPoint
from cv_bridge import CvBridge
import numpy as np
import torch
from lerobot.common.policies.factory import make_policy

class VLAPolicyNode(Node):
    def __init__(self):
        super().__init__('vla_policy_node')

        # Parameters
        self.declare_parameter('policy_path', '')
        self.declare_parameter('control_freq', 10.0)
        self.declare_parameter('device', 'cuda')

        policy_path = self.get_parameter('policy_path').value
        self.device = self.get_parameter('device').value
        control_freq = self.get_parameter('control_freq').value

        # Load policy
        self.get_logger().info(f'Loading policy from {policy_path}...')
        self.policy = make_policy(
            cfg=None,
            pretrained_policy_name_or_path=policy_path,
        )
        self.policy.to(self.device)
        self.policy.eval()
        self.get_logger().info('Policy loaded successfully!')

        # State
        self.bridge = CvBridge()
        self.latest_image = None
        self.latest_joints = None

        # Subscribers
        self.image_sub = self.create_subscription(
            Image, '/camera/color/image_raw', self.image_callback, 10
        )
        self.joint_sub = self.create_subscription(
            JointState, '/joint_states', self.joint_callback, 10
        )

        # Publisher
        self.action_pub = self.create_publisher(
            JointTrajectoryPoint, '/policy_action', 10
        )

        # Control loop timer
        period = 1.0 / control_freq
        self.timer = self.create_timer(period, self.control_loop)
        self.get_logger().info(f'Control loop at {control_freq} Hz')

    def image_callback(self, msg):
        self.latest_image = self.bridge.imgmsg_to_cv2(msg, 'rgb8')

    def joint_callback(self, msg):
        self.latest_joints = np.array(msg.position)

    def control_loop(self):
        if self.latest_image is None or self.latest_joints is None:
            return

        # Prepare observation
        obs = {
            'observation.images.top': torch.from_numpy(
                self.latest_image
            ).permute(2, 0, 1).unsqueeze(0).float().to(self.device) / 255.0,
            'observation.state': torch.from_numpy(
                self.latest_joints
            ).unsqueeze(0).float().to(self.device),
        }

        # Predict action
        with torch.no_grad():
            action = self.policy.select_action(obs)

        action_np = action.squeeze().cpu().numpy()

        # Publish
        msg = JointTrajectoryPoint()
        msg.positions = action_np.tolist()
        msg.time_from_start.sec = 0
        msg.time_from_start.nanosec = int(1e8)  # 100ms
        self.action_pub.publish(msg)

def main():
    rclpy.init()
    node = VLAPolicyNode()
    rclpy.spin(node)
    node.destroy_node()
    rclpy.shutdown()

if __name__ == '__main__':
    main()

Debugging Common Failures

Failure Taxonomy

Action Smoothing Filter

class ActionSmoother:
    """Exponential moving average for smooth actions."""

    def __init__(self, alpha=0.7, action_dim=7):
        self.alpha = alpha
        self.prev_action = np.zeros(action_dim)
        self.initialized = False

    def smooth(self, raw_action):
        if not self.initialized:
            self.prev_action = raw_action.copy()
            self.initialized = True
            return raw_action

        smoothed = self.alpha * raw_action + (1 - self.alpha) * self.prev_action
        self.prev_action = smoothed.copy()
        return smoothed

# Usage
smoother = ActionSmoother(alpha=0.7)
smoothed_action = smoother.smooth(raw_policy_action)

Complete Deployment Checklist

Pre-deployment

• Camera intrinsic calibration (reprojection error < 0.5px)
• Hand-eye calibration (position error < 5mm)
• Joint order matches training (verify with manual test)
• Action space bounds verified against robot limits
• Emergency stop (e-stop) tested and accessible
• Workspace boundaries configured in software
• Inference latency measured (< 200ms for 5Hz control)
• GPU memory sufficient (check with nvidia-smi)

During deployment

• Start with slow speed (10% of max velocity)
• Run 5 episodes with soft objects first
• Monitor joint torques — spikes indicate collision
• Log all observations and actions for post-analysis
• Gradually increase speed over 20+ successful episodes

Post-deployment

• Calculate success rate over 50+ episodes
• Analyze failure modes (categorize using table above)
• Collect real-world failure cases for fine-tuning
• Compare sim vs real performance gap

Real-World Fine-tuning với LeRobot

Nếu sim-trained policy đạt < 80% trên real robot, fine-tune trên real data là bước tiếp theo:

from lerobot.common.datasets.lerobot_dataset import LeRobotDataset
from lerobot.common.policies.diffusion.modeling_diffusion import DiffusionPolicy

# 1. Collect 50-100 real demonstrations
# (dùng teleop giống bài 2, nhưng trên robot thật)

# 2. Load sim-pretrained policy
policy = DiffusionPolicy.from_pretrained("my-sim-trained-policy")

# 3. Load real dataset
real_dataset = LeRobotDataset("my-real-demos")

# 4. Fine-tune with lower learning rate
from lerobot.scripts.train import train
train(
    policy=policy,
    dataset=real_dataset,
    training_steps=10000,        # Ít hơn sim training
    learning_rate=1e-5,          # 10x thấp hơn
    batch_size=32,
    eval_freq=1000,
)

Chiến lược này được gọi là sim-to-real-to-sim — train trong sim, fine-tune trên real, rồi dùng real data để improve sim.

Tổng kết Series

Qua 10 bài, chúng ta đã xây dựng complete pipeline:

1. Framework deep dive — hiểu LeRobot từ trong ra ngoài
2. Data collection — thu thập demonstration quality
3. Single-arm training — ACT vs Diffusion Policy
4. Multi-object — scaling lên nhiều vật thể
5. Long-horizon — multi-step task planning
6. Dual-arm setup — bimanual calibration
7. Dual-arm tasks — coordination training
8. Mobile manipulation — base + arms
9. Humanoid — whole-body control
10. Sim-to-Real (bài này) — deployment pipeline

LeRobot đang phát triển rất nhanh — theo dõi GitHub repo để cập nhật. Chúc bạn deploy thành công!

Tài liệu tham khảo

• Domain Randomization for Transferring Deep Neural Networks — Tobin et al., 2017
• Sim-to-Real Robot Learning from Pixels with Progressive Nets — Rusu et al., 2017
• Closing the Sim-to-Real Loop — Chebotar et al., 2019
• LeRobot: State-of-the-art Machine Learning for Real-World Robotics — Hugging Face, 2024
