Sim-to-Real cho Humanoid: Deployment Best Practices

Bài cuối: Từ Sim đến Robot thật

Xuyên suốt 9 bài trước, chúng ta đã train humanoid đi (G1, H1), chạy (H1 advanced), bê vật (loco-manip), và parkour (bài 9) — tất cả trong simulation. Bây giờ là bước quan trọng nhất và cũng khó nhất: deploy lên robot thật.

Sim-to-real cho humanoid khó hơn quadruped (xem locomotion sim2real) vì: bipedal inherently unstable, narrow support polygon, higher center of mass, và nhiều DOF hơn. Một sai lầm nhỏ có thể khiến robot ngã và hư hỏng phần cứng trị giá hàng chục ngàn đô.

Domain Randomization Checklist cho Humanoid

Physical Parameters

class HumanoidDomainRandomization:
    """Domain randomization config cho humanoid sim-to-real."""

    def __init__(self):
        self.params = {
            # --- Body dynamics ---
            "base_mass_range": [0.85, 1.15],      # ±15% total mass
            "link_mass_range": [0.9, 1.1],         # ±10% per link
            "com_offset_range": [-0.02, 0.02],     # ±2cm CoM offset
            "inertia_range": [0.8, 1.2],           # ±20% inertia

            # --- Joint properties ---
            "joint_friction_range": [0.0, 0.05],   # Joint friction
            "joint_damping_range": [0.5, 2.0],     # Damping coefficient
            "joint_armature_range": [0.01, 0.05],  # Reflected inertia
            "joint_stiffness_range": [0.0, 5.0],   # Spring stiffness

            # --- Actuator ---
            "motor_strength_range": [0.85, 1.15],  # ±15% max torque
            "motor_offset_range": [-0.02, 0.02],   # Position offset (rad)

            # --- Ground ---
            "ground_friction_range": [0.4, 1.5],   # Friction coefficient
            "ground_restitution_range": [0.0, 0.3], # Bounciness

            # --- Delays & noise ---
            "action_delay_range": [0, 30],         # ms (0-2 sim steps)
            "observation_delay_range": [0, 15],    # ms
            "action_noise_std": 0.02,              # Action noise
            "joint_pos_noise_std": 0.01,           # Joint encoder noise
            "joint_vel_noise_std": 0.1,            # Joint velocity noise
            "imu_noise_std": 0.05,                 # IMU noise
            "imu_bias_range": [-0.1, 0.1],         # IMU bias

            # --- External perturbations ---
            "push_force_range": [0, 50],           # Random push (N)
            "push_interval_range": [5, 15],        # Seconds between pushes
            "push_duration": 0.1,                  # Push duration (s)

            # --- Terrain ---
            "terrain_roughness_range": [0.0, 0.03], # Height variation
        }

    def randomize(self, env):
        """Apply randomization to environment."""
        import numpy as np

        for key, (low, high) in self.params.items():
            value = np.random.uniform(low, high)
            env.set_param(key, value)

        return env

So sánh Sim vs Real Gaps

System Identification

Motor Identification

import numpy as np
from scipy.optimize import minimize

class MotorIdentification:
    """Identify real motor parameters from data."""

    def __init__(self, joint_name, dt=0.002):
        self.joint_name = joint_name
        self.dt = dt

    def collect_data(self, robot, duration=10.0):
        """Collect torque-position-velocity data."""
        data = {'pos': [], 'vel': [], 'torque': [], 'cmd': []}

        # Chirp signal for frequency response
        t = 0
        while t < duration:
            freq = 0.5 + t / duration * 5.0  # 0.5 → 5.5 Hz
            cmd = 0.3 * np.sin(2 * np.pi * freq * t)

            robot.set_joint_position(self.joint_name, cmd)

            state = robot.get_joint_state(self.joint_name)
            data['pos'].append(state.position)
            data['vel'].append(state.velocity)
            data['torque'].append(state.effort)
            data['cmd'].append(cmd)

            t += self.dt

        return {k: np.array(v) for k, v in data.items()}

    def identify(self, data):
        """Fit motor model to collected data."""
        pos = data['pos']
        vel = data['vel']
        torque = data['torque']
        cmd = data['cmd']

        def motor_model(params, cmd, pos, vel):
            """Simple motor model: tau = Kp*(cmd-pos) - Kd*vel - friction*sign(vel)"""
            Kp, Kd, friction, damping = params

            predicted_torque = (
                Kp * (cmd - pos)
                - Kd * vel
                - friction * np.sign(vel)
                - damping * vel
            )
            return predicted_torque

        def objective(params):
            pred = motor_model(params, cmd, pos, vel)
            return np.mean((pred - torque) ** 2)

        # Initial guess
        x0 = [100.0, 5.0, 0.5, 0.1]
        bounds = [(10, 500), (0.1, 50), (0, 5), (0, 2)]

        result = minimize(objective, x0, bounds=bounds, method='L-BFGS-B')

        Kp, Kd, friction, damping = result.x
        print(f"Joint {self.joint_name}:")
        print(f"  Kp = {Kp:.1f}, Kd = {Kd:.2f}")
        print(f"  Friction = {friction:.3f}, Damping = {damping:.3f}")
        print(f"  MSE = {result.fun:.6f}")

        return {
            'Kp': Kp, 'Kd': Kd,
            'friction': friction, 'damping': damping,
        }

Real-Time Inference trên Onboard Computer

Unitree Robot Compute Options

Optimized Policy Inference

import torch
import time
import numpy as np

class PolicyInference:
    """Optimized policy inference cho real-time control."""

    def __init__(self, policy_path, device='cuda'):
        self.device = device

        # Load policy
        checkpoint = torch.load(policy_path, map_location=device)
        self.policy = checkpoint['policy']
        self.policy.eval()

        # JIT compile cho speed
        dummy_input = torch.zeros(1, self.obs_dim).to(device)
        self.policy_jit = torch.jit.trace(self.policy, dummy_input)
        self.policy_jit = torch.jit.freeze(self.policy_jit)

        # Observation normalization stats
        self.obs_mean = checkpoint['obs_mean'].to(device)
        self.obs_std = checkpoint['obs_std'].to(device)

        # Action scaling
        self.action_scale = checkpoint.get('action_scale', 0.25)
        self.default_dof_pos = checkpoint['default_dof_pos']

        # Pre-allocate tensors (avoid allocation in control loop)
        self.obs_tensor = torch.zeros(1, self.obs_dim, device=device)

    def normalize_obs(self, obs):
        """Normalize observation using training stats."""
        return (obs - self.obs_mean) / (self.obs_std + 1e-8)

    @torch.no_grad()
    def get_action(self, obs_np):
        """Get action from observation (numpy → numpy)."""
        # Copy to pre-allocated tensor
        self.obs_tensor[0] = torch.from_numpy(obs_np).float()

        # Normalize
        obs_norm = self.normalize_obs(self.obs_tensor)

        # Inference
        action = self.policy_jit(obs_norm)

        # Scale and offset
        target_pos = (
            self.default_dof_pos +
            action.squeeze() * self.action_scale
        )

        return target_pos.cpu().numpy()

    def benchmark(self, n_iterations=1000):
        """Benchmark inference speed."""
        obs = np.random.randn(self.obs_dim).astype(np.float32)

        # Warm up
        for _ in range(100):
            self.get_action(obs)

        # Measure
        times = []
        for _ in range(n_iterations):
            start = time.perf_counter()
            self.get_action(obs)
            torch.cuda.synchronize()
            times.append(time.perf_counter() - start)

        mean_ms = np.mean(times) * 1000
        std_ms = np.std(times) * 1000
        max_ms = np.max(times) * 1000

        print(f"Inference: {mean_ms:.2f} ± {std_ms:.2f} ms")
        print(f"Max: {max_ms:.2f} ms")
        print(f"Control freq: {1000/mean_ms:.0f} Hz")

Safety Systems

Safety Layer Architecture

class HumanoidSafetyLayer:
    """Safety layer between policy and actuators."""

    def __init__(self, robot_config):
        self.config = robot_config

        # Joint limits (soft + hard)
        self.soft_limits = robot_config['soft_joint_limits']  # Warning
        self.hard_limits = robot_config['hard_joint_limits']  # Clamp

        # Velocity limits
        self.max_joint_vel = robot_config['max_joint_velocity']  # rad/s

        # Torque limits
        self.max_torque = robot_config['max_torque']  # Nm per joint

        # Fall detection
        self.min_base_height = 0.3  # meters (G1: 0.4, H1: 0.6)
        self.max_tilt_angle = 60.0  # degrees

        # E-stop state
        self.e_stop_active = False

    def check_and_apply(self, target_positions, current_state):
        """Apply safety checks and return safe commands."""

        if self.e_stop_active:
            return self._damping_mode(current_state)

        # 1. Fall detection
        if self._detect_fall(current_state):
            print("FALL DETECTED — activating damping mode")
            self.e_stop_active = True
            return self._damping_mode(current_state)

        # 2. Joint limit clamping
        safe_positions = np.clip(
            target_positions,
            self.hard_limits[:, 0],
            self.hard_limits[:, 1]
        )

        # 3. Velocity limiting
        current_pos = current_state['joint_positions']
        delta = safe_positions - current_pos
        max_delta = self.max_joint_vel * self.config['dt']
        safe_positions = current_pos + np.clip(delta, -max_delta, max_delta)

        # 4. Soft limit warning
        for i, (pos, (lo, hi)) in enumerate(
            zip(safe_positions, self.soft_limits)
        ):
            if pos < lo or pos > hi:
                print(f"WARNING: Joint {i} near limit: {pos:.3f} "
                      f"[{lo:.3f}, {hi:.3f}]")

        return safe_positions

    def _detect_fall(self, state):
        """Detect if robot is falling."""
        base_height = state['base_position'][2]

        # Check height
        if base_height < self.min_base_height:
            return True

        # Check tilt (roll and pitch)
        roll = np.degrees(state['base_euler'][0])
        pitch = np.degrees(state['base_euler'][1])
        if abs(roll) > self.max_tilt_angle or abs(pitch) > self.max_tilt_angle:
            return True

        return False

    def _damping_mode(self, state):
        """Zero torque + damping — robot goes limp safely."""
        return state['joint_positions']  # Hold current position

    def reset_estop(self):
        """Manual e-stop reset."""
        self.e_stop_active = False
        print("E-stop reset — resuming normal operation")

Deployment Framework: Unitree SDK + ROS 2

Complete Control Loop

#!/usr/bin/env python3
"""Humanoid locomotion deployment on Unitree G1/H1."""

import numpy as np
import time
from unitree_sdk2py.core.channel import ChannelPublisher, ChannelSubscriber
from unitree_sdk2py.idl.unitree_go.msg.dds_ import LowCmd_, LowState_

class HumanoidDeployment:
    """Deploy RL locomotion policy on Unitree humanoid."""

    def __init__(self, policy_path, robot_type='g1'):
        # Load policy
        self.policy = PolicyInference(policy_path)

        # Safety layer
        self.safety = HumanoidSafetyLayer(
            ROBOT_CONFIGS[robot_type]
        )

        # Robot config
        self.config = ROBOT_CONFIGS[robot_type]
        self.dt = self.config['control_dt']  # 0.02s = 50Hz

        # Observation buffer
        self.obs_history = []
        self.history_len = 10

        # Action filter
        self.action_filter = ExponentialFilter(alpha=0.8)

        # State
        self.running = False
        self.iteration = 0

    def build_observation(self, state):
        """Construct observation vector from robot state."""
        obs = np.concatenate([
            state['base_angular_velocity'],      # (3,) from IMU
            state['projected_gravity'],           # (3,) gravity in body frame
            self.velocity_command,                # (3,) vx, vy, vyaw
            (state['joint_positions'] -
             self.config['default_dof_pos']),     # (N,) joint pos offset
            state['joint_velocities'],            # (N,) joint velocities
            self.previous_action,                 # (N,) last action
        ])

        # Clip observation
        obs = np.clip(obs, -100.0, 100.0)

        return obs

    def control_step(self, state):
        """Single control step: obs → policy → safety → command."""
        # 1. Build observation
        obs = self.build_observation(state)

        # 2. Policy inference
        raw_action = self.policy.get_action(obs)

        # 3. Action filtering (smooth)
        filtered_action = self.action_filter.apply(raw_action)

        # 4. Convert to target positions
        target_positions = (
            self.config['default_dof_pos'] +
            filtered_action * self.config['action_scale']
        )

        # 5. Safety check
        safe_positions = self.safety.check_and_apply(
            target_positions, state
        )

        # 6. Store for next iteration
        self.previous_action = filtered_action.copy()
        self.iteration += 1

        return safe_positions

    def run(self, velocity_command=[0.5, 0.0, 0.0]):
        """Main control loop."""
        self.velocity_command = np.array(velocity_command)
        self.previous_action = np.zeros(self.config['num_dof'])
        self.running = True

        print(f"Starting deployment: vel_cmd = {velocity_command}")
        print(f"Control frequency: {1/self.dt:.0f} Hz")
        print("Press Ctrl+C to stop")

        try:
            while self.running:
                loop_start = time.perf_counter()

                # Read state
                state = self.read_robot_state()

                # Compute action
                target_pos = self.control_step(state)

                # Send command
                self.send_command(target_pos)

                # Timing
                elapsed = time.perf_counter() - loop_start
                sleep_time = self.dt - elapsed
                if sleep_time > 0:
                    time.sleep(sleep_time)
                elif elapsed > self.dt * 1.5:
                    print(f"WARNING: Control loop overrun: "
                          f"{elapsed*1000:.1f}ms > {self.dt*1000:.1f}ms")

        except KeyboardInterrupt:
            print("\nStopping — entering damping mode")
            self.safety.e_stop_active = True


class ExponentialFilter:
    """Exponential moving average filter for actions."""

    def __init__(self, alpha=0.8):
        self.alpha = alpha
        self.prev = None

    def apply(self, x):
        if self.prev is None:
            self.prev = x.copy()
            return x

        filtered = self.alpha * x + (1 - self.alpha) * self.prev
        self.prev = filtered.copy()
        return filtered


# Robot configurations
ROBOT_CONFIGS = {
    'g1': {
        'num_dof': 23,
        'control_dt': 0.02,      # 50 Hz
        'action_scale': 0.25,
        'max_joint_velocity': 10.0,  # rad/s
        'default_dof_pos': np.zeros(23),  # Standing pose
        'soft_joint_limits': np.array([[-2.0, 2.0]] * 23),
        'hard_joint_limits': np.array([[-2.5, 2.5]] * 23),
        'max_torque': np.array([50.0] * 23),
        'dt': 0.02,
    },
    'h1': {
        'num_dof': 19,
        'control_dt': 0.02,
        'action_scale': 0.25,
        'max_joint_velocity': 10.0,
        'default_dof_pos': np.zeros(19),
        'soft_joint_limits': np.array([[-2.0, 2.0]] * 19),
        'hard_joint_limits': np.array([[-2.5, 2.5]] * 19),
        'max_torque': np.array([80.0] * 19),
        'dt': 0.02,
    },
}

Debugging Common Failures

Complete Deployment Checklist

Pre-Deployment

• System identification done (motor params, friction, latency)
• Domain randomization ranges cover identified real values
• Policy trained with history observations (for deployment without privileged info)
• Safety layer tested with simulated failures
• E-stop hardware tested and accessible
• Soft floor/mats placed in testing area
• Inference benchmarked on target compute (< 5ms cho 50Hz)
• Battery fully charged (>80%)

First Test Protocol

• Start with robot hanging on gantry/harness — no ground contact
• Verify joint tracking with sinusoidal commands
• Lower to ground with zero velocity command (standing only)
• Send very slow velocity command (0.1 m/s forward)
• Gradually increase to target velocity over 20+ minutes
• Test push recovery with gentle pushes
• Test on flat ground before any terrain

Monitoring During Deployment

• Log all observations, actions, torques at full rate
• Monitor joint temperatures (thermal protection)
• Monitor battery voltage (shutdown if <20%)
• Camera recording for post-analysis
• Always have someone within arm's reach of e-stop

Tổng kết Series

Tài liệu tham khảo

1. Learning Humanoid Locomotion with Transformers — Radosavovic et al., 2024
2. Real-World Humanoid Locomotion with RL — Gu et al., 2024
3. Humanoid-Gym: Reinforcement Learning for Humanoid Robot — Gu et al., 2024
4. Sim-to-Real Transfer for Bipedal Locomotion — Li et al., 2023

Bài viết liên quan

• Sim-to-Real cho Locomotion: Thực tế và kinh nghiệm
• Domain Randomization: Chìa khóa Sim-to-Real
• Humanoid Parkour: Jumping, Climbing và Obstacle Course
